Toyota LC200, Tundra (XK50) & Lexus LX570 (16-21) Alcon Big Brake kit

SKU BKF1559K18
Save 14% Save 16%
Original price $3,850.00 USD
Original price $2,675.00 USD - Original price $6,525.00 USD
Original price $3,850.00 USD
Current price $3,230.00 USD
$2,275.00 USD - $5,615.00 USD
Current price $3,230.00 USD
⭐ All Brake Kits ship FREE to the USA.
βœ”οΈGuaranteed Fit for Your Vehicle
βœ”οΈExpert Support from the Largest Alcon Dealer in the U.S.
Location: Stage 1 - Front only
Ask a question

This information is a general guide for wheels that fit this brake kit. For βœ”guaranteed fit (only applicable if you buy direct from Alconkits.com) check using the wheel template below. Instructions on use.

Tested wheels that fit:

18-inch Toyota Alloy 5-Spoke (42611-60A50)
17-inch Toyota Steel β€˜Pepperpot’ (42611-60A60)
355mm rotors require 17" and larger wheels

FRONT KIT: 17" wheels with 355mm use BKF1559K18 template to check your wheels for fit.

Alcon LC200 TUV Certified. Click here:

Explore common maintenance items for this brake kit.

Service Parts - Front Kit
Rotors - DIV3430X985C24
Pads - PNS4415X502.4
Calipers - CIR1559K08HZL/R
Brackets - BSK4415X577
Pin kit - PKR4415X540KS
Brake Line Kit - MHA3430X761
Bleed Screws - 03.3518-0066.1

Service Parts - Rear kit
Rotors - DIV3430X964C24
Pads - PNS0084X449S.4
Calipers - CIR5059D01HZLT/RT
Brackets - BSK4450X566
Pin Kit - PKR4450X304KS
Brake Line Kit - MHA3430X745
Bleed Screws - 03.3518-0066.1

Specifications:

Manufacturer:
Alcon Brakes
SKU:
BKF1559K18
UPC:
854071008416
Shipping Weight:
105.0 lbs
Location:
Stage 1 - Front only

PRODUCT INFORMATION

Alcon Armored/Off-Road 2016-2021 Toyota LC200, Toyota Tundra and Lexus LX570 complete brake kit. The front kit uses 6 piston calipers with 355mm x 36mm. The rear has 4 piston calipers and 370mm x 28mm rotors. 45% reduced brake temperature for more reliable stops in heavy duty applications. Select the front/rear bundle for additional discount. This is for the XK50 Chassis.Β

This kit is TUV Certified. Click for certificate.

Specified for:

Front kit up to 9,900 lbs (4500kg) weight
Front/Rear kit up to 14,300 lbs (6500kg) weight

***Does NOT fit with aftermarket spindles, Camburg, etc.. ***

Looking for a custom color to compliment your truck?

Calipers come zinc plated from the factory. If you want something else, our expert customization shop will get you *exactly* the color and finish you want. (Custom colors add 2-3 weeks for the work)


APPLICATION NOTES

  • The thicker steel washers are to be installed between the caliper and the bracket.Β  The thinner washers go under the caliper to bracket bolt head.
  • Validate caliper bracket bolts must be M14 to use this kit.
  • Does not fit with aftermarket spindles
  • Dust Shields may need to be modified either cutting or removing for proper fitment

These kits were designed through extensive testing in Alcon’s military and armored program for many years and are an extremely effective and proven platform used worldwide by both NGO and official vehicles.

Benefits

  • 45% reduction in brake disc temperature rise
  • 42% reduction in pad work rate for longer life and more torque
  • 10% less pedal effort
  • 10% increase in brake torque.

Featuring

  • Ductile iron calipers for the best abrasion resistance. No worries about rock and debris strikes
  • Zinc finish for maximum corrosion protection and subtle OEM look. (Custom powdercoating is available!)
  • High friction/High temp brake pads
  • Larger rotors for shorter stopping distance every time, not just the first or second stop.
  • High temperature seals
  • Fits under most 17" and 18" wheels
  • Bleed screws on the inboard side for impact protection and tamper resistance.

Front Includes:

  • SIX piston front calipers measuring 41.3mm each
  • Front 355mm (14.0") x 36mm (1.4") rotors internally vented
  • AV1 Compound Brake Pads
  • Brackets
  • Stainless Brake Lines

Rear includes:

  • FOUR piston rear calipers 34.9mm ea.
  • Rear 370mm (14.5") x 28mm (1.2") rotors internally vented.
  • AV1 Compound Brake Pads
  • Brackets
  • Stainless Brake Lines



Service Parts - Front Kit
Rotors - DIV3430X985C24
Pads - PNS4415X502.4
Calipers - CIR1559K08HZL/R
Brackets - BSK4415X577
Pin kit - PKR4415X540KS
Brake Line Kit - MHA3430X761
Bleed Screws - 03.3518-0066.1

Service Parts - Rear kit
Rotors - DIV3430X964C24
Pads - PNS0084X449S.4
Calipers - CIR5059D01HZLT/RT
Brackets - BSK4450X566
Pin Kit - PKR4450X304KS
Brake Line Kit - MHA3430X745
Bleed Screws - 03.3518-0066.1

SKU: BKF1559K18

Alcon Big Brake Kit common questions

Alconkits - the primary Alcon distributor

Why should you buy direct from AlconKits.com?

General retailers and marketplaces list Alcon brake kits, but they typically cannot advise on fitment, wheel clearance, pad compounds, or long-term service parts. You can buy Alcon Brakes from lots of places - but you SHOULD buy them from Alconkits.com. Alconkits.com is a specialist distributor focused exclusively on Alcon systems.

What support do I get when buying from Alconkits.com?

You get brake experts live every time. We answer the phone with 25 years of Alcon Brakes support. Our experts will help you choose the right kit, with the right fit, guaranteed. Plus, when you need replacement parts and service knowledge, you will only get that from Alconkits.com - not someone who just sells general automotive parts.

What happens if I need pads, rotors, or service parts later?

This is an excellent question to ask. We stock replacement parts for everything we sell - and maintain a full cross-reference catalog for all compatible parts. When you buy from Alconkits.com an authorized primary distributor of Alcon Brakes you will get a lifetime of advice and support that other vendors cannot match.

Is Alconkits.com an authorized Alcon distributor?

Yes. You can find authorized dealers on the manufacturers website - and we are seen as one of the largest most knowledgeable dealers in the world, and certainly in the United States.

What are the main reasons people choose Alconkits?
  1. Factory-engineered systems designed for brake performance and durability require expert advice
  2. Lifetime technical support included when purchased from Alconkits.com.
  3. Support beyond just sale, we help you select pads, ensure fitment, and service your brakes.

In short, you want an expert driven purchase decision, from a vendor that provides value beyond the product, with service, support, and expertise. That is the Alconkits.com promise delivered every day.

Installation

What tools do I need to install?

Our brake kits require common hand tools for installation. You will need a torque wrench, brake fluid (2 pints), and loctite.

What if I run into issues while installing?

We pride ourself in expert advice. You can call or text us at 630-360-2548 for expert technical and installation advice.

Are any other modifications required?

For OEM installations where wider rotors are fitted, you should expect to remove or trim the rotor dust/heat shield. This often interferes with larger rotors but is no longer needed due to our upgraded components.

Will I need a new Master Cylinder

No. All of our brake kits are designed specifically to work with the hydraulic ratio of your stock master cylinder

Do I need wheel spacers

We provide a fitment template for you to check clearance in advance. In some cases a small spacer may be required and we provide those when we are sure they are needed.

Are brake pads included?

Yes. We include the appropriate brake pads for all our brake kits. In some cases we offer multiple compounds for you to customize your experience. We stock a wide variety of pads for Alcon Brake kits here.

Break In questions

Do I need to brake in new rotors/pads?

Yes! We highly recommend following our brake pad/rotor bed in process. This ensures that an even layer of pad material is deposited on the rotor to eliminate shudder, increase rotor life, and to heat temper the new rotors for longer life.

What about noise and dust?

Noise and dust are related to the brake pad compound. Higher temp pads have more metallic composition and will therefore increase potential noise and dust the more aggressive the pad. For squealing issues we recommended loosening the caliper and re tightening it. This will sometimes change the caliper "frequency". Additionally "sticky shims" or our titanium pad shims will reduce noise.

Operational Questions

Is this compatible with my ABS?

Yes! We test our brakes to ensure they are fully compatible with your stock ABS on all models we release.

How long do they last?

Lifetime of components is massively variable based on how they are used. High dust/dirt/salt environments will wear seals out more quickly. Heavy Duty or Track use will also affect rotor and pad life.

What is the warranty?

We support the manufacturers 12 month/12000 mile warranty against factory defects and material issues. You can find more details here.
